ABB 81EU01E-E GJR2391500R1210 Input Module For Binary And Analog Transmitters
Product Details:
| Brand Name | ABB |
| Model | 81EU01E-E GJR2391500R1210 |
| Product ID | GJR2391500R1210 |
| Condition | New |
| Gross Weight | 2.2 lbs / 35.2 oz / 1kg |
| Packing Size | 6.4" x 6.4" x 4.8" (16cm x 16 cm x 12 cm) |
| Country of Origin | Sweden (SE) |
| Lead Time | In Stock |
| Shipping Port | Xiamen |
| Payment | T/T |
| Sales Price | Inquiry |
| Color | Depends on material |
| Warranty | 12 months |
| Lead time | 5-8 work days |
| Courier partners | DHL, UPS, TNT, FedEx and EMS |
Additional Information:
| Number of Channels: | 16 |
| Input Type | Universal |
| Voltage | -20Vto +20 V |
| Current | -20 mA to +20 mA |
| Resistance | 0Ω to 2kΩ |
| Accuracy | 0.5% |
| Response Time | <2ms |
| Operating Temperature | -20℃ to +60℃ |
Description:
The ABB 81EU01E-E GJR2391500R1210 is a 16-channel universal input module used in the ABB Ability System 800xA® control system. It provides flexibility for interfacing with various sensors and switches in industrial applications. It allows modules to be replaced without powering down the system. Channels can be individually configured for analog or digital input. The module incorporates a total of 5 function units. Each function unit may be used for any type of input mode. Any combination is possible. The allocation as well as the settings of all the parameters can be programmed easily using the configuration list.
The ABB GJR2391500R1210 serves as a universal input module within the S800 1/0 system, facilitating the connection of 16 sensors or switches to a controller. Designed for versatility, it accommodates various signals such as voltage, current, and resistance. With easy DIN rail mounting and communication options including AF100, PROFIBUS-DP, or direct connection, it offers flexibility in installation and integration. The programmed values are stored in an EEPROM to ensure that they are not lost in the event of a power failure. They can be changed any time. Every analog signal can be assigned up to 4 limit values. In an input module, up to 5 independent correction or filter calcuations can be carried out. Programming is done by structuring function blocks.
The ABB GJR231500R1210 81EU01E-E is indeed a versatile universal input module with robust features tailored for industrial automation applications. It accepts a wide range of signals including voltage, current, temperature (up to 150°C), and various RTD types. This is likely an electronic device or component used in industrial automation and control systems. It could be a module, interface, or another type of electronic unit. Key specifications may include power requirements, input/output characteristics, and compatibility with other components or systems.
These components are commonly used in industrial automation, motor control, and other electrical systems where reliable switching and power distribution are crucial. This 16-channel universal input module bridges the gap between your ABB Ability System 800xA controller and a wide range of industrial sensors and switches. Accommodates voltage, current, and resistance signals, offering adaptability to your specific application needs.
Datasheet Link:
ABB 81EU01E-E GJR2391500R1210.pdf
