Product Details:

Description:

The 81AA03A-E GJR2394100R1210 is part of ABB Procontrol P14 I/O module. It is an Output module for analog signals 8 fold. The output module is used to output analog signals in the signal ranges 0 to 20 mA or 4 to 20 mA. This module can be plugged into any Procontrol station. It incorporates a standard interface to the Procontrl station bus. The signals to be outputted are received by the unit in the form of telegrams from the Procontrol bus system via the station bus. This module can be plugged into any Procontrol station. It incorporates a standard interface to the Procontrol station bus.

The signals to be outputted are received by the unit in the form of telegrams from the Procontrol bus system via the station bus. The telegrams are checked for error- free transfer by means of the parity bits before being outputted. The signals to be outputted are received by the unit in the form of telegrams from the PROCONTROL bus system via the station bus.The telegrams are checkedfor error-free transfer by means of the parity bits before being outputted. Digital-to-analog conversionis performed with a 12-bit resolution.

The 81AA03A-E GJR2394100R1210 is the combination of quick supply with applied discount against your old faulty card. This ABB output module is designed for industrial automation systems, offering precise control over output signals with exceptional reliability and efficiency. The 8 channels output module is used to output analog signals in the signal ranges 0 to 20 mA or 4 to 20 mA. The 81AA03A-E GJR2394100R1210 is the combination of quick supply with applied discount against your old faulty card.

The analog signal outputs are short-circuit-proof and protected against mutual interference. They have a common reference conductor The analog inputs are isolated fom the module's intemal voltage and from the PROCONTROL bus. Within the module, the signals are transferred to the outputs via optocouplers. Whenever an internal monitoring circuit responds, this is indicated on the module's front panel by an SG(module disturbance) and an ST(general disturbance) disturbance annunciation.

ABB Analog Output Module

81AA03A-E Control Board

GJR2394100R1210 Control Board

ABB 81AA03A-E GJR2394100R1210 Control Board Analog Output Module Images
